Functionality

Product Overview

Touch screen

Touch screen technology offers easy and user friendly human interface. Reliable surface acoustic wave technology (SAW) with fast response, accurate dual-touch capability and immunity to unintentional touch is used.

INOX housing

Industrial design results in very robust new age outlook. Only the best materials are used to achieve natural look. Housing is highly resistant to environmental influences.

Industrial printer

Heavy duty industrial printer is integrated for applications that demand fast and reliable printing. High performance thermal printing mechanism with easy maintenance, long life cycle, high printing speed technology is used.

Glass front panel

Thick toughened glass brings pure and straight lines and makes this product recognizable and glamorous. Discreet shine stands out and welcomes customers to use the machine.

Additional customization

For special applications and needs Bank Note Acceptor, Coin Dispenser can be integrated.

Company logo

Logo with ice-white or RGB LED backlight makes this product recognizable in your company colors. A stronger machine personalization effect is achieved because of initial design integration.

EMV POS payment solution

Embedded POS application for EMV bank transactions processing is integrated. Credit and debit cards can be used for bank transactions. Other types of chip or magnetic cards can be integrated.

Pinpad

2D barcode scanner

Simple manual omnidirectional barcode scanner is often used for bill payment applications. It provides a very fast and reliable way of data acquisition.

A6 3D scanner

Motorized scanner for bill payment applications is integrated. It provides a reliable and accurate result for acquiring and further data processing.

Equipment

Technical specification

  • Size: 17-inch
  • Indoor/outdoor versions
  • Resolution: 1280x1024 pixels
  • Touch technology: dual-touch SAW
  • Brightness: 250/800
  • Contrast ratio: 1000:1

  • High-quality finish
  • Precise manufacturing
  • Durable and resistant

  • Printing technology: thermal
  • Paper width: 60 to 80 mm
  • Resolution: 200 dpi
  • Speed: > 140 mm/s
  • Highly reliable cutter: > 1,000,000 cuts

  • LED lightning
  • SW control via RS232
  • Simple protocol

  • Laser or thermal technology
  • Front paper output
  • Speed: thermal-80 mm/s, laser-33 ppm
  • Resolution: thermal-300 dpi, laser-1200 dpi
  • Interface: USB

  • Tempered glass
  • Thickness: 8 mm
  • Curved edges
  • Custom colors/design

  • EN 60950-22:2006, EMC directive 2004/108/EC, EN 61000-6-1:2007,
  • EN 55022:1998+A1:2000+A2:2005, EN 61000-3-2:2006, EN 61000-3-3:2008,
  • IEC 60950-1:2005(2nd edition), EN 60950-1:2006

  • Input voltage: 230 VAC / 50 Hz
  • IP protection: IPx4

  • Ice-white or custom color LED backlight
  • Seamless front-panel integration
  • Maximum dimensions: 340x120 mm

  • Backlit yellow/green display 128x64 pixels
  • Ethernet communication (GPRS optional)
  • 15 keys
  • VISA PED and PCI-ready

  • Major credit/debit cards supported
  • Chip & PIN fully capable
  • Extensible for additional payment systems
  • Easy integration with local processors
  • Industry standards

  • Technology: hybrid card reader
  • Supported cards: magstripe & chip
  • Magstripe reader: ISO 1, 2, 3
  • Smart card reader: EMV, ISO7816
  • Compliance: PCI PED & EMV 4.0

  • All major 1D and 2D barcode standards supported
  • LED light source 330 LUX @ 130 mm
  • CMOS sensor resolution 752x480
  • RS232 interface

  • Resolution: 200 dpi
  • Selectable image format
  • Speed: 22 inch/s
  • OCR, OMR, BCR and MICR data
  • Document size: A6 to 2.27-inch
  • Reflection-free light source
  • USB interface

  • LAN FTP CAT5 10/100 Mbps
  • 6xRS232/485/422
  • LICY 4 x 0.75 mm²

Usage

Product application

Bank utilization

Info kiosk for banking purposes brings benefits to retail net and customers. Customer bank account related information services can be offered. An easy and fast way to inform customers about new services that a bank would like to introduce. Customer wait time is shorter — more satisfaction is brought to the customers. Personal bank account information printing is available for customers who regularly check info at front office desk. Queuing machine system for administering queues is implemented using web-based technologies — easy implementation and best price performance solution.

Telecom fix and mobile operators utilization

Bill payment functionality improves service efficiency and brings more satisfaction to clients. Electronic input minimizes human error and decreases transaction time while no personnel utilization is needed. Electronic payment ensures lower transaction costs and brings more profit. Prepaid recharge can be done via different technologies: electronic vouchers can be printed directly on-site; direct top-up can be done via DOV technology. Also, other technologies can be implemented.

Loyalty

Acquiring and retaining loyal customers is one of the primary goals in sales business. Using info kiosk and loyalty cards for interaction with customers brings limitless possibilities for bonus and loyalty programs. Our system provides you with valuable long-term communication with the customer and tools for data mining and analysis of customer habits.
